Also sold as the Ten-Tec R4040

General characteristics

HAM bands
80m  40m  30m (WARC)  20m  6m
Frequency stability
?
Tuning steps
10 / 100 Hz, 1 / 100 kHz
Memories
30 channels in 1 bank(s)

Receiver

RX-range
3.2-16 MHz
Modulations
CW   USB
Sensitivity
?
Selectivity
4 crystal filter, 400Hz-3KHz continued adjustable
Filters
?
Receiver system
?
IF-frequencies
400 Hz - 3 kHz
Image rejection
?
Audio output
8ohm load about 0.1W

Transmitter

TX-range
3.5-4 / 7.0-7.3 / 10.1-10.15 / 14.0-14.35 MHz
80 / 40 / 30 / 20 m
Modulations
CW
RF-output
4-5 W @ 13.8 V

Connections

Antenna
BNC
Impedance
?
Other
-

Electrical

Power requirements
11.1 V battery pack or 9-14 V DC
Current drain RX
60 mA
TX
800 mA

Physical

Dimensions (w×h×d)
132 × 85 × 35 mm (5.20 × 3.35 × 1.38 in)
Weight
380 gr (13.4 oz)
Form factor
Handheld
Manufactured
Between 201x and 201x

Other features

Usage
Amateur / Ham radio operators
Features + options
Auto key w/ adjustable speed
Accessories
-
RigReference ID
6027
MPN
YOUKITS-HB-000001B

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Youkits HB-1B. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Youkits HB-1B is around:

  • USD 243.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2017 USD 270.00 New / Mint RigReference
