General characteristics

HAM bands
2m  70cm
Frequency stability
± 2.5 p.p.m.
Tuning steps
5 / 6.25 kHz
Memories
4000 channels in 1 bank(s)

Receiver

RX-range
136-174 / 400-480 MHz
Modulations
FM   N-FM   DMR
Sensitivity
FM: 0.25 µV (12 dB SINAD)
NFM: 0.35 µV (12 dB SINAD)
DMR: 0.3 µV (BER 5%)
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
≥ 60 dB
Audio output
1 W at 5% distortion / 16 ohms

Transmitter

TX-range
136-174 / 400-480 MHz
Modulations
FM   N-FM   DMR
RF-output
6 / 5 / 2.5 / 1 W

Connections

Antenna
SMA
Impedance
50Ω
Other
-

Electrical

Power requirements
7.4 V DC
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
61 × 129 × 39 mm (2.40 × 5.08 × 1.54 in)
Weight
282 gr (10.0 oz) with 2100 mAh Li-Ion battery and antenna
Form factor
Handheld
Manufactured
Between 2018 and 20xx in China

Other features

Usage
Amateur / Ham radio operators
Features + options
DMR APRS reporting
1.7" TFT display
10000 talk groups and 150000 contacts
Auto-sense DMR or FM reception
GPS
Accessories
-
RigReference ID
6419
MPN
ANYTONE-AT-D000878UV

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Anytone AT-D878UV. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Anytone AT-D878UV is around:

  • USD 238.00 ~ USD 216.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2022 USD 314.99 New / Mint Gary Pinson
2021 USD 299.00 New / Mint GabrielRadio
2020 USD 250.00 New / Mint Patrick
2020 USD 250.00 New / Mint Patrick
2019 USD 239.95 New / Mint René Champagne
