Retevis RT3S

General characteristics

HAM bands

2m  70cm

Frequency stability

±1 ppm

Tuning steps

?

Memories

3000 channels in bank(s)

Receiver

RX-range

136-174 / 400-480 MHz

Modulations

FM   DMR

Sensitivity

Analog: 0.2 µV (12 dB SINAD)
Digital: 0.25 µV (5% BER)

Selectivity

Adjacent channel: 60 dB (12.5 kHz)

Filters

?

Receiver system

?

IF-frequencies

?

Image rejection

?

Audio output

1 W (16 ohm)

Transmitter

TX-range

136-174 / 400-480 MHz

Modulations

FM   DMR

RF-output

5 / 1 W

Connections

Antenna

-

Impedance

50Ω

Other

-

Electrical

Power requirements

7.4 V DC Li-ion, 2000 mAh

Current drain RX

?

TX

?

Physical

Dimensions (w×h×d)

61 × 131 × 36 mm (2.40 × 5.16 × 1.42 in)

Weight

258 gr (9.1 oz) With battery

Form factor

Handheld

Manufactured

Between 20xx and 20xx in China

Other features

Usage

Amateur / Ham radio operators

Features + options

Dual-band DMR Tier I/II and analog
GPS (GPS and non-GPS versions)
AMBE+2 vocoder, ETSI TS 102 361-1/-2/-3
Dual time slot
3000 channels, 10,000 contacts
Recording
Encryption, lone worker
Remote kill / stun / activate
VOX, TOT, emergency alarm

Accessories

-

RigReference ID

6726

MPN

RETEVIS-RT000003S

Similar rigs

Manuals, diagrams and brochures

No manuals yet for the Retevis RT3S. Have a PDF of the user manual, service manual, or schematic? Upload it and help the next operator.



Upload relevant documents

Reviews

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Retevis RT3S. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic price data, today's estimated value of the Retevis RT3S in Good condition is around:

• USD 122
