Retevis A61

General characteristics

HAM bands

2m  70cm

Frequency stability

±2.5 ppm

Tuning steps

?

Memories

999 channels in bank(s)

Receiver

RX-range

136-520 MHz
AM airband: 108-136 MHz
FM broadcast: 65-108 MHz

Modulations

AM   FM   N-FM   W-FM

Sensitivity

0.25 µV (12 dB SINAD)

Selectivity

60 dB (25 kHz) / 55 dB (12.5 kHz)

Filters

?

Receiver system

?

IF-frequencies

?

Image rejection

?

Audio output

1 W (16 ohm), distortion 5% or less

Transmitter

TX-range

US: 144-148 / 420-450 MHz
EU: 144-146 / 430-440 MHz

Modulations

FM   N-FM

RF-output

High / middle / low

Connections

Antenna

-

Impedance

50Ω

Other

-

Electrical

Power requirements

Li-ion, 2200 mAh; charging 5 V 1 A

Current drain RX

350 mA or less (standby 85 mA)

TX

1.8 A or less (high), 650 mA (low)

Physical

Dimensions (w×h×d)

?

Weight

?

Form factor

Handheld

Manufactured

Between 20xx and 20xx in China

Other features

Usage

Amateur / Ham radio operators

Features + options

Dual-band handheld with GPS
999 channels
AM airband and FM broadcast receive

Accessories

-

RigReference ID

6732

MPN

RETEVIS-A000061

Similar rigs

Manuals, diagrams and brochures

No manuals yet for the Retevis A61. Have a PDF of the user manual, service manual, or schematic? Upload it and help the next operator.



Upload relevant documents

Reviews

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Retevis A61. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on similar Transceiver equipment, the estimated value of the Retevis A61 is around:

• USD 203 ~ USD 377

This estimate is based on similar equipment and may not reflect the exact value of this model.

These estimates are based on the following prices:
