ICOM ID-800D

Mobile VHF/UHF Transceiver

View all reviews (0) Add a review Add to my shack



Login or Register to upload images

Find ICOM ID-800D rigs and spare parts on eBay Find the ICOM ID-800D on Amazon
We receive a small fee when you buy through these links, thank you!

D-Star concept.

Frequency range

RX-range
118-174 / 230-550 / 834-915 / 960.1-1000 MHz
TX-range
144-146 / 430-440 MHz
HAM bands
?
Stability
?
Tuning steps
?
Filters
?

Receiver

Modulations
AM   FM   N-FM   GMSK
Sensitivity
?
Selectivity
FM: 12 kHz (-6 dB), 30 kHz (-60 dB)
N-FM: 6 kHz (-6 dB), 20 kHz (-60 dB)
Receiver system
?
IF-frequencies
?
Image rejection
60 dB
Audio output
?

Transmitter

Modulations
FM   N-FM
RF-Output
High: 50/50 W, Medium: 15/15 W, Low: 5/5 W

Connections

Antenna
N-type
Impedance
50 Ω

Electrical

Power requirements
13.8V DC
Current drain RX
Max 1.1 A
TX
Max 12.5 A

Physical

Dimensions (w×h×d)
141 × 40 × 39 mm (5.55 × 1.57 × 1.54 in) transceiver
Weight
1.20 kg (2.6 lbs)
Form factor
Mobile
Manufactured
Between 2004 and 200x in Japan
MPN
ICOM-ID-000800D

Other features

Memories
512 channels in 1 bank(s)
Usage
Amateur / Ham radio operators
Features + options
GPS option.
Accessories
?
