General characteristics

HAM bands
?
Frequency stability
± 2.5 p.p.m.
Tuning steps
5 / 6.25 / 10 / 12.5 / 25 / 50 / 100 kHz
Memories
128 channels in 1 bank(s)

Receiver

RX-range
76-108 / 136-174 / 400-480 MHz
Modulations
FM   N-FM
Sensitivity
0.16µV (12dB SINAD)
Selectivity
12.5 / 25 kHz
Filters
?
Receiver system
Double conversion superheterodyne
IF-frequencies
?
Image rejection
?
Audio output
500mW max

Transmitter

TX-range
136-174 / 400-470 MHz
Modulations
FM   N-FM
RF-output
VHF: 5W, UHF: 4W max

Connections

Antenna
SMA
Impedance
50Ω
Other
-

Electrical

Power requirements
7.4V DC
Current drain RX
?
TX
?

Physical

Dimensions (w×h×d)
59 × 119 × 37 mm (2.32 × 4.69 × 1.46 in)
Weight
246 gr (8.7 oz)
Form factor
Handheld
Manufactured
Between 2010 and 201x in China

Other features

Usage
Amateur / Ham radio operators
Features + options
Speech synthesizer
DCS/CTCSS/DTMF
Stopwatch
PC-programmable
CE-compliant
Built-in flashlight
Alpha tags
Roger beep
VOX
Twin RX
Accessories
-
RigReference ID
5429
MPN
WOUXUN-KG-UV000002D
