The Yaesu FTV-650 six meter transverter converts a 10/11 m rig into a 6 m rig. The input frequency between 28 and 30 MHz is converted to either 50-52 or 52-54 MHz in SSB or AM modes. The Yaesu FTV-650 was designed to work together with the Yaesu FT-101 / Yaesu FT-201 transceiver or Yaesu FL-101 / Yaesu FR-101 transmitter-receiver combination.
General characteristics
- HAM bands
- 11m (CB) 6m 10m
- Frequency stability
- ?
- Tuning steps
- ?
- Memories
- None
Receiver
- RX-range
- 28-30 MHz
- Modulations
- AM SSB
- Sensitivity
- 0.5 µV @ 10 dB S/N for SSB
1.0 µV @ 10 dB S/N for AM - Selectivity
- ?
- Filters
- ?
- Receiver system
- ?
- IF-frequencies
- ?
- Image rejection
- ?
- Audio output
- ?
Transmitter
- TX-range
- 28-30 MHz
- Modulations
- AM SSB
- RF-output
- 50 W PEP
Connections
- Antenna
- SO-239
- Impedance
- 50Ω
- Other
- -
Electrical
- Power requirements
- 11-pin connector from transceiver
- Current drain RX
- ?
- TX
- ?
Physical
- Dimensions (w×h×d)
- ?
- Weight
- ?
- Form factor
- Base Station
- Manufactured
- Between 199x and 199x in Japan
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- -
- Accessories
- -
- RigReference ID
- 5660
- MPN
- YAESU-FTV-000650
Manuals, diagrams and brochures
- Yaesu FTV-650 Circuit diagram JPG - Unknown size, submitted by RigReference
- Yaesu FTV-650 Instructions PDF - Unknown size, submitted by RigReference
- Yaesu FTV-650 picture JPEG - 292.5 kB, submitted by IZ5IUY
- Yaesu Musen FTV-650 front view photo JPEG - 2.64 MB, submitted by IZ5IUY
- Yaesu Musen FTV-650 rear view photo JPEG - 2.38 MB, submitted by IZ5IUY
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Yaesu FTV-650. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
Based on historic price data, today's estimated value of the Yaesu FTV-650 in Good condition is around:
- USD 44 ~ USD 73
These estimates are based on the following prices:
