Successor to the ICOM IC-R20. This new model has extremely wide coverage. Modes of reception include: FM, W-FM, AM, (SSB) USB, LSB, CW and digital modes including P25 (Phase 1 Conventional), D-STAR™, NXDN™ (Conventional) and dPMR™ (Conventional). It is dual-watch capable, simultaneously receiving and recording two frequencies (except digital signals). Band A covers 100 kHz to 3304.999990 MHz (less cellular) and Band B 108-520.000 MHz with up to 2000 memory channels. A microSD card slot supports the audio record function and receiver programming data. MicroSD card sold separately. It even has an integrated GPS for position logging of recorded communications. Convenient USB charging and full speed USB data transfer. Spectrum display. The radio has built-in Bluetooth® and a free downloadable Android™ remote control app will be provided. It meets IP57 standards for water resistance and dust protection.

General characteristics

HAM bands
?
Frequency stability
?
Tuning steps
?
Memories
2000 channels in 1 bank(s)

Receiver

RX-range
0.1-3305 MHz (cellular blocked in the US)
Modulations
AM   FM   W-FM   CW   USB   LSB   D-STAR   P25   DV
Sensitivity
?
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Connections

Antenna
SMA
Impedance
50Ω
Other
-

Electrical

Power requirements
?
Current drain RX
?
TX
-

Physical

Dimensions (w×h×d)
?
Weight
?
Form factor
Handheld
Manufactured
Between 2018 and 20xx in Japan

Other features

Usage
Amateur / Ham radio operators
Features + options
Bluetooth
Dual-watch
IP57 environmental proof
Micro-SD card
Sprectrum display
Audio recording
GPS
Accessories
-
RigReference ID
6324
MPN
ICOM-IC-R000030

Manuals, diagrams and brochures

IC R30 ENG BM-0 PDF - 2.84 MB, submitted by Sofyan Kurniawan
IC R30 ENG PU-2 PDF - 3.94 MB, submitted by Sofyan Kurniawan
IC R30 LT PDF - 1.73 MB, submitted by Sofyan Kurniawan
IC R30 Procuct Brochure PDF - 1.24 MB, submitted by Sofyan Kurniawan
IC R30 High Resolution Image TIFF - 2.80 MB, submitted by Sofyan Kurniawan

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used ICOM IC-R30. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the ICOM IC-R30 is around:

  • USD 610.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2020 USD 639.00 New / Mint GigaParts
