General characteristics

HAM bands
2m  70cm
Frequency stability
±1.0 p.p.m.
Tuning steps
?
Memories
3000 channels in 1 bank(s)

Receiver

RX-range
76-107.95 / 136-174 / 400-480 MHz
Modulations
FM   DMR
Sensitivity
Analog
0.35 µV / -116dBm (20dB SINAD)
0.22 µV / -120dBm (Type)
Digital
0.30 µV / -117dBm (BER 5%)
0.70 µV / -110dBm (BER 1%)
Selectivity
?
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
≥500mW

Transmitter

TX-range
136-174 / 400-480 MHz
Modulations
FM   DMR
RF-output
VHF: 1 / 5 / 10 W, UHF: 1 / 4 / 8 W

Connections

Antenna
-
Impedance
?
Other
-

Electrical

Power requirements
7.4 V DC 3200 mAh Li-ion
Current drain RX
?
TX
Analog ≤1.6A, Digital ≤0.9A

Physical

Dimensions (w×h×d)
150 × 64 × 40 mm (5.91 × 2.52 × 1.57 in)
Weight
360 gr (12.7 oz) with battery
Form factor
Handheld
Manufactured
Between 2017 and 201x in China

Other features

Usage
Amateur / Ham radio operators
Features + options
CTCSS / DTS
1000/1450/1750/2100Hz Single tone
Digital Protocol ETSI TS 102 361-1,-2,-3
Motorola Tier Ⅰ&
IP67 Waterproof
Optional encryption
Accessories
-
RigReference ID
6257
MPN
AILUNCE-HD000001

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Reviews & stories

Do you know this rig? Tell us something about it!

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Ailunce HD1. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Ailunce HD1 is around:

  • USD 135.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2017 USD 189.00 New / Mint RigReference
