Retevis RT72 Digital Dual band 4000 channels Two Way Radio ham radio amateur radio GPS
General characteristics
- HAM bands
- 2m 70cm
- Frequency stability
- ± 1 p.p.m.
- Tuning steps
- 12.5 kHz
- Memories
- 4000 channels in 1 bank(s)
Receiver
- RX-range
- 136-174 / 400-470 MHz
- Modulations
- FM N-FM FSK DMR
- Sensitivity
- Analog: -122dBm (12dB SINAD)
Digital: -120dBm(BER≤5%) - Selectivity
- ?
- Filters
- ?
- Receiver system
- ?
- IF-frequencies
- ?
- Image rejection
- ?
- Audio output
- 1 W
Transmitter
- TX-range
- 136-174 / 400-470 MHz
- Modulations
- FM N-FM FSK DMR
- RF-output
- 1 / 5 W
Connections
- Antenna
- SMA
- Impedance
- 50Ω
- Other
- -
Electrical
- Power requirements
- 7.4 V DC 1700 mAh Li-ion
- Current drain RX
- 180 mA
- TX
- 0.9-1.6 A
Physical
- Dimensions (w×h×d)
- 133 × 62 × 36 mm (5.24 × 2.44 × 1.42 in)
- Weight
- 274 gr (9.7 oz) including in battery and antenna
- Form factor
- Handheld
- Manufactured
- Between 2019 and 202x in China
Other features
- Usage
- Amateur / Ham radio operators
- Features + options
- -
- Accessories
- -
- RigReference ID
- 6502
- MPN
- SKU A9185A
Manuals, diagrams and brochures
-
No documents available for this particular model.
- Upload relevant documents
New and second-hand prices
Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Retevis RT72. Just bought or sold this model? Let us know what you traded it for and help other ham operators!
Based on historic data, today's second-hand price of the Retevis RT72 is around:
- USD 90.00
These estimates are based on the following prices:
