Frequency range

RX-range
118-524 / 800-1300 MHz
TX-range
144-148 / 430-450 MHz
HAM bands
?
Stability
?
Tuning steps
?
Filters
?

Receiver

Modulations
AM   FM
Sensitivity
<0.16 µV (12 dB SINAD)
Selectivity
11 kHz (-6 dB), 30 kHz (-50 dB)
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

Modulations
FM
RF-Output
High: 50/50 W, Medium: 10/10 W, Low: 5/5 W

Connections

Antenna
SO-239
Impedance
50 Ω

Electrical

Power requirements
13.8V DC
Current drain RX
Max 1.2 A
TX
4-13 A

Physical

Dimensions (w×h×d)
140 × 43 × 181 mm (5.51 × 1.69 × 7.13 in) Panel: 1404338 mm
Weight
1.50 kg (3.3 lbs)
Form factor
Unknown
Manufactured
Between 2007 and 200x
MPN
KENWOOD-TM-V000071A

Other features

Memories
1000 channels in 1 bank(s)
Usage
Amateur / Ham radio operators
Features + options
WX alert. CTCSS/DCS. Digital voice recorder option. Twin RX
Accessories
?

Manuals, diagrams and brochures

No documents available for this particular model.

Upload relevant documents

Show other documents.
Find the Kenwood TM-V71A user manuals on eBay #ad

Reviews & stories

Great dual bander

Kenwood TM-V71A, VHF/UHF Transceiver

I have used it for about 4 months now. Great little rig. I used the Kenwood MCP-2 software to program it. Easy as all get out once you understand the software. My last dual bander mobile was 25 years ago so the learning curve was a little steep for my 64 yr old brain. Outstanding recieve audio and what comes out the other end is about the best I have heard. My better half is also a ham so I know exactly how she sounds. She drives the radio better because of a higher pitch voice than mine. The manual is OK. The reason for the ok is that I think it needs to go into more depth in all areas. I like the bigger hand mike as my hands are big. A little more to grab on to so to speak. 1000 memories Wow. My last dual band had 50!!!!! I like the capability to program things into sections. i.e. frequencies from my home to Dallas or for a large metro area. Weather alert tone is loud. Had it programed to go off and just about jumped out of my skin the other day. Still looking for a way to turn it down a bit. This radio is the Best investment I have made recently. You will not be disappointed if you purchase one of these radios.

John

Overall

Performance
Build quality
Features
User friendlyness
Value for money
Aquired
Good condition in 2010
USD 0.00

Excellent 2M/70CM Transceiver

Kenwood TM-V71A, VHF/UHF Transceiver

Great radio. I can reach all the area repeaters and have made a few simplex contacts with it.

Overall

Performance
Build quality
Features
User friendlyness
Value for money
Aquired
Mint condition in 2013
USD 379.99

What's it worth

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the current value of the Kenwood TM-V71A. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's value of the Kenwood TM-V71A might be around:

  • USD 285.00
Year Historic price Condition Submitted by
2013 USD 379.99 New / Mint 1094Jacob
2013 USD 355.00 New / Mint k6avi
2016 USD 290.00 Used / Mint eBay
