General characteristics

HAM bands
2m
Frequency stability
?
Tuning steps
?
Memories
1000 channels in 1 bank(s)

Receiver

RX-range
118-524 / 800-1300 MHz
Modulations
AM   FM
Sensitivity
<0.16 µV (12 dB SINAD)
Selectivity
11 kHz (-6 dB), 30 kHz (-50 dB)
Filters
?
Receiver system
?
IF-frequencies
?
Image rejection
?
Audio output
?

Transmitter

TX-range
144-148 / 430-450 MHz
Modulations
FM
RF-output
High: 50/50 W, Medium: 10/10 W, Low: 5/5 W

Connections

Antenna
SO-239
Impedance
50 Ω
Other
-

Electrical

Power requirements
13.8V DC
Current drain RX
Max 1.2 A
TX
4-13 A

Physical

Dimensions (w×h×d)
140 × 43 × 181 mm (5.51 × 1.69 × 7.13 in) Panel: 1404338 mm
Weight
1.50 kg (3.3 lbs)
Form factor
Unknown
Manufactured
Between 2007 and 200x

Other features

Usage
Amateur / Ham radio operators
Features + options
WX alert. CTCSS/DCS. Digital voice recorder option. Twin RX
Accessories
-
RigReference ID
3434
MPN
KENWOOD-TM-V000071A

Manuals, diagrams and brochures

TM V71 PDF - 4.48 MB, submitted by Berend

Upload relevant documents

Reviews & stories

Rating Title Submitted
Excellent 2M/70CM Transceiver 11 years ago by 1094Jacob
Great dual bander 14 years ago by oldranger1

New and second-hand prices

Estimating the value of a rig can be challenging. We collect prices paid by real hams over the years to help you estimate the value of a used Kenwood TM-V71A. Just bought or sold this model? Let us know what you traded it for and help other ham operators!

Based on historic data, today's second-hand price of the Kenwood TM-V71A is around:

  • USD 175.00 ~ USD 268.00

Price History Chart

These estimates are based on the following prices:

Year Historic price Condition Submitted by
2021 USD 375.00 New / Mint WILKEY
2020 USD 281.00 Used / Good eBay
2016 USD 290.00 Used / Mint eBay
2014 USD 360.00 New / Mint KV4NK
2013 USD 379.99 New / Mint 1094Jacob
